Mobile Phone Thermal Imaging Thermometer Thermal Night Vision Devices
parameter:
| Detector type | Uncooled focal plane micro-heat type | |
| Pixel | 160×120 | |
| Wavelength range | 8-14um | |
| Pixel spacing | 17um | |
| NETD | ≤0.06℃@30℃ | |
| frame rate | 25Hz | |
| FOV | 37°×28° | |
| Spatial resolution | 4.4mrad | |
| Focus range | 0.2m~∞ | |
| Focusing method | Focus-free | |
| Image enhancement | DDE | |
| Image storage | APP supports photo and video | |
| Image display | Infrared image/visible light/picture in picture | |
| Color palette | 11 color palettes to choose from (including iron red, rainbow, black and white, black and white reverse, etc.) | |
| Image format | Infrared picture JPEG format, video MPEG4 format | |
| Temperature range | -10℃- +300℃ | |
| Precision | ±2℃ or ±2% (reading range), whichever is greater | |
| measurement correction | Auto | |
| measurement mode | Center point, highest point/lowest point, movable point, regional temperature measurement | |
| Working temperature | -40℃-+60℃ | |
| storage temperature | -40℃~+70℃ | |
| |
| Protection level | IP54 | |
| fall | 2m | |
| weight | 33g | |
| dimension | 57mm×25mm×23.5mm | |
| Power connector | USB Type-C DC 5V | |
| Power consumption | 450mW | |
| |
| Software update | Support | |
Application
• Make you an expert in temperature measurement
• HVAC system testing
• Electrical equipment fever detection
• Hidden dangers detection of weak electricity in buildings
• Open the eyes of colorful thermal images
• Water pipe leakage detection
• Heating failure detection
• Air conditioning maintenance detection
• Interesting detection, interesting sightseeing, interesting exploring
• Night security inspection
• Animal search
• Privacy & security, it will find hidden pinhole cameras
Main features
• Infrared video capture
• Photo storage
• Full temperature measurement
• High and low temperature alarm
• Central point temperature measurement
• Highest point/lowest point temperature measurement
• Movable point, regional temperature measurement
• Multi-mode image display
• Infrared/Visible Light/Picture in Picture
• 15 kinds of pseudo-color modes for auxiliary observation
• Sensitive and precise
• 0.06℃ sensitivity, perceive subtle temperature changes
• ±2℃(±2%) Accurate temperature measurement, accurate identification of abnormality
• Focus-free, minimum detection distance of 0.1m, efficient inspection in small spaces
• Self-developed core with military standard
• 160×120 pixels uncooled infrared focal plane detector
• Full coverage of temperature measurement scene: temperature measurement range: -10℃~300℃
• Portable, lightweight and drop-proof
• 2m drop resistance
• Ultra low power consumption, smartphone power supply
Scope of application
• Electrical diagnosis
• Industrial inspection
• HVAC overhaul
• Home inspection
• outdoor sports
• Privacy security
